PE PP pelletizing line
PE/PP film compactor type pelletizing line
SJ series PE/PP film pelletizing line is the special equipment for the film pelletizing. With compactor machine, it could pre-compact the thin material into the small granule, making the automatic feeding easier, and it improves the production capacity effectively. Cylinder type hydraulic filter with vacuum gas exhausting enables the non-stop changing filter and no leaking material. Pelletizing by die-face-cut improves the pelletizing quality.
| Model | Screw Diameter
(mm) |
Rotary Speed (rpm) | Main motor
(kw) |
Compactor
(kw) |
Capacity
(kg/h) |
| SJ85-33 | 85 | 10-120 | 55 | 37 | 150-180 |
| SJ100-33 | 100 | 10-120 | 90 | 55 | 250-300 |
| SJ130-33 | 130 | 10-120 | 132 | 75 | 300-400 |
| SJ160-33 | 160 | 10-120 | 160 | 90 | 500-600 |
| SJ180-33 | 180 | 10-120 | 250 | 132 | 800-1000 |
